Frequency Response

45 Hz - 25 kHz 3dB

Frequency Response

45 Hz - 25 kHz 3dB

1I

Sensitivity

91 dB/1 Watt/1 meter

Sensitivity

86 dB/1 Watt/1 meter

I

Impedance

Nominal 4 Ohms

Impedance

Nominal 8 Ohms

I

Recommended Power

20 - 300 Watts per channel

Recommended Power

20 - 200 Watts per channel

I

Drivers

One - 1" tweeter

Drivers

One - 1" tweeter

I

Two - 5-1/2" woofers

One - 5-1/2" woofer

I

Termination

Gold plated binding posts

Termination

Gold plated binding posts

I

Size

7.5" x 22.5" x 10"  (H x W x D)

Size

14" x 7.5" x 10"  (H x W x D)

I

Weight

Net weight 28 lbs each

Weight

Net weight 20 lbs each




Frequency Response

35 Hz - 25 kHz 3dB 35 Hz - 25 kHz 3dB

Frequency Response

40 Hz - 25 kHz 3dB

1I

Sensitivity

86 dB/1 Watt/1 meter

Sensitivity

91 dB/2.83V/1 meter

I

Impedance

Nominal 8 Ohms

Impedance

Nominal 4 Ohms

I

Recommended Power

20 - 300 Watts per channel

Recommended Power

20 - 300 Watts per channel

I

Drivers

One - 1" tweeter

Drivers

One - 1" tweeter

I

One - 7" woofer

Two - 5-1/2" woofers

I

Termination

Gold plated binding posts

Termination

Gold plated binding posts

I

Size

38" x 8" x 10"  (H x W x D)

Size

38" x 7.5" x 10"  (H x W x D)

I

Weight

Net weight 50 lbs each

Weight

Net weight 50 lbs each










Frequency Response

35 Hz - 25 kHz 3dB

Sensitivity

91 dB/2.83V/1 meter

Impedance

Nominal 4 Ohms

Recommended Power

20 - 500 Watts per channel

Drivers

One - 1" tweeter

Two - 7" woofers

Termination

Gold plated binding posts

Size

43" x 8" x 13"  (H x W x D)

Weight

Net weight 70 lbs each
