Frequency Response

45 Hz - 25 kHz 3dB

Sensitivity

90 dB/2.83V/1 meter

Impedance

Nominal 4 Ohms

Recommended Power

20 - 300 Watts

Drivers

One - 1" tweeter

Two - 5-1/2" woofers

Termination

Gold plated binding posts

Size

7.5" x 22.5" x 10"  (H x W x D)

Weight

Net weight 28 lbs each

















Frequency Response

45 Hz - 25 kHz 3dB

1I

Sensitivity

85 dB/2.83V/1 meter

I

Impedance

Nominal 8 Ohms

I

Recommended Power

20 - 300 Watts

I

Drivers

One - 1" tweeter

One - 5-1/2" woofer

I

Termination

Gold plated binding posts

I

Size

13" x 7" x 10"  (H x W x D)

I

Weight

Net weight 19 lbs each

Frequency Response

40 Hz - 25 kHz 3dB

1I

Sensitivity

86 dB/2.83V/1 meter

I

Impedance

Nominal 8 Ohms

I

Recommended Power

20 - 300 Watts

I

Drivers

One - 1" tweeter

One - 7" woofer

I

Termination

Gold plated binding posts

I

Size

17" x 8" x 12"  (H x W x D)

I

Weight

Net weight 28 lbs each





Frequency Response

35 Hz - 25 kHz 3dB

1I

Sensitivity

86 dB/2.83V/1 meter

I

Impedance

Nominal 8 Ohms

I

Recommended Power

20 - 300 Watts

I

Drivers

One - 1" tweeter

One - 7" woofer

I

Termination

Gold plated binding posts

I

Size

38" x 8" x 10"  (H x W x D)

I

Weight

Net weight 55 lbs each







Frequency Response

40 Hz - 25 kHz 3dB

1I

Sensitivity

90 dB/2.83V/1 meter

I

Impedance

Nominal 4 Ohms

I

Recommended Power

20 - 500 Watts

I

Drivers

One - 1" tweeter

Two - 5-1/2" woofers

I

Termination

Gold plated binding posts

I

Size

38" x 7.5" x 10"  (H x W x D)

I

Weight

Net weight 50 lbs each




























Frequency Response

30 Hz - 25 kHz 3dB

Sensitivity

90 dB/2.83V/1 meter

Impedance

Nominal 4 Ohms

Recommended Power

20 - 500 Watts per channel

Drivers

One - 1" tweeter

Two - 7" woofers

Termination

Gold plated binding posts

Size

43" x 8" x 13"  (H x W x D)

Weight

Net weight 70 lbs each




































Frequency Response

25 Hz - 25 kHz 3dB

Sensitivity

87 dB/2.83V/1 meter

Impedance

Nominal 8 Ohms

Recommended Power

50 - 500 Watts per channel

Drivers

One - 1" tweeter

One - 5-1/2" midrange

One - 9" woofer

Termination

Gold plated binding posts

Size

43" x 9.5" x 15.5"  (H x W x D)

Weight

Net weight 88 lbs each
